Features
- 5 years safety and quality guaranteed: In addition to the 2-year statutory warranty, we give a further 3-year Webasto guarantee for free
- Cost savings for installation thanks to integrated DC residual current protection
- Remote access by the grid operator to ensure grid stability
-? Configurable charging capacity at various levels up to 22 kW
? - Integrated type 2 charging cable with 4.5m cable length
-? Convenient cable suspension and plug socket
? - Charging station operating status display in optimized LED design
-? Access control with universal key switch
? - Easy-to-use charging station (plug & play)
? - Easy installation and fast start-up
? - Made in Germany for high-quality manufacturing

Technical Specifications
ELECTRICAL CHARACTERISTICS
- Nominal current:
• 8A, 10A, 13A, 16A, 20A, 25A, 32A
• Splitphase (L1+L2, without N) single phase, 2-phase or 3-phase
- Line voltage: 230/400V AC
- Line frequency: 50 Hz
- Network forms: TT / TN (single- and 3-phase) / IT (single-phase)
- EMC class:
• Interference emission: Class B (residential, business, commercial areas)
• Interference resistance: residential, business, commercial areas
- Overvoltage category: III as per EN 60664
- Protection class: I
- Necessary protective equipment: Residual current circuit breaker RCD type A and miniature circuit breakers must be provided on the installation side
- Integrated protective equipment: 6mA DC residual current detection

CONNECTIONS
- Mounting: Wall or stand mounting (permanently connected)
- Cable feed: Mounted on-wall or in-wall
- Connection cross-section (wire dimension): Cross-section of the connecting cable (Cu) taking into account the local conditions and norms 6 mm2 (for 16 A) - 10 mm2 (for 32 A)
- Charging cable with charging coupling: Type 2 cable according to EN 62196-1 and EN 62196-2
• Length: 4.5m - cable bracket integrated
• Output voltage: 230/400V AC
• Max. Charging power: 22 kW

FEATURES
- Locking mechanism: Universal key switch
- Display: LED light bar (RGB), buzzer
- External control interface: Potential-free contact

MECHANICAL DATA
- Dimensions (W×H×D): 225×447×116 mm
- Weight: 5.7 kg
- IP protection class, device: IP54
- Protection against mechanical impact: IK08

AMBIENT CONDITIONS
- Operating temperature range: -30C to +45C (without direct solar radiation)
- Storage temperature range: -30C to +80C
- Permissible relative humidity: 5% to 95% non-condensing
- Altitude: Max. 3.000m above sea level

CERTIFICATION
- Other standards and guidelines:
• CE conformity
• 2014 / 53 / EU Radio Equipment Directive
• 2014 / 30 / EU EMV conformity
• 2011 / 65 / EU RoHS Directive
• 2001 / 95 / EC General Product Safety
• 2012 / 19 / EU Waste Electrical and Electronic Equipment Directive
• 1907 / 2006 REACH Regulation
