USW-48-PoE is 48-Port managed PoE switch with (48) Gigabit Ethernet ports including (32) 802.3at PoE+ ports, and (4) SFP ports. Powerful second-generation UniFi switching.
| Proizvođač: | Ubiquiti Networks |
| Šifra: | 1388726 |
| Kataloški broj: | USW-48-POE-EU |
| Jamstvo: | 24 |
| Raspoloživost: |
(Dobavljivo)
|
Prosječna ocjena:
0,00
| Glasova:
0
|
| Ocijeni
ovaj proizvod
|
716,00 €
**kod nonSEPA transakcija naplaćujemo naknadu banke
već od 22,10 €/mjesečno
Odabrali ste prikaz cijena za gotovinsko plaćanje - prikaži MPC
USW-48-PoE is 48-Port managed PoE switch with (48) Gigabit Ethernet ports including (32) 802.3at PoE+ ports, and (4) SFP ports. Powerful second-generation UniFi switching.
Switch 48 PoE
In Stock
SKU: USW-48-PoE-EU
Summary
Datasheet
Installation Guide
A 48-port, Layer 2 PoE switch with a silent, fanless cooling system.
Features:
(32) GbE, PoE+ RJ45 ports
(16) GbE RJ45 ports
(4) 1G SFP ports
195W total PoE availability
1.3" LCM color touchscreen with AR switch management
Mechanical
Dimensions 442.4 x 285 x 43.7 mm (17.42 x 11.22 x 1.72")
Weight Without mounting brackets: 4.52 kg (9.97 lb)
With mounting brackets: 4.61 kg (10.16 lb)
Enclosure material SGCC steel
Hardware
Networking interface (48) 10/100/1,000 RJ45 ports
(4) 1G SFP Ethernet ports
Management interface Ethernet In-Band
Total non-blocking throughput 52 Gbps
Switching capacity 104 Gbps
Forwarding rate 77.38 Mpps
Power method 100—240V AC, 50/60 Hz, universal input
Power supply AC/DC, internal, 240W
Supported voltage range 100—240V AC
Max. power consumption 45W (Excluding PoE output)
ESD/EMP protection Air: ± 16kV, contact: ± 12kV
Shock and vibration ETSI300-019-1.4 Standard
Operating temperature -5 to 40° C (23 to 104° F)
Operating humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
LEDs
System Status
Ethernet PoE
Speed/link/activity
SFP+ Link/activity
PoE
Total available PoE 195W
PoE interfaces
Ports 1-32
PoE/PoE+ (Pins 1, 2+; 3, 6-)
Max. PoE wattage per port by PSE
PoE+
32W
Voltage range PoE mode 44—57V
Voltage range PoE+ mode 50—57V
| Zaštita PGR 5 godina (2+3) - 60,00 € |
| Osnovne karakteristike | |
|---|---|
| Portova: | 48 |
| Brzina prijenosa podataka: | 1 Gbps |
| Kućište: | Ugradbeno 1U |
| POE: | Da |
| Konektori | |
| SFP: | 4 |
*Unatoč uloženom trudu da damo što bolji i točniji opis, slike i specifikacije, ne možemo garantirati da su svi navedeni podaci točni te ne odgovaramo za eventualne pogreške nastale u opisu proizvoda, slika ili specifikacija. Iste je potrebno provjeriti na stranicama proizvođača ili pošaljite upit našim djelatnicima da provjere.
Ukoliko na našoj stranici otkrijete neistinite odnosno neadekvatne informacije, molimo vas da nam to javite na prodaja[o]protis.hr
Za odabrani proizvod nije unesen niti jedan komentar.
