4MP super high resolution and 24-hour full colorPeople and vehicle classificationSmart detectionSmart video enhancement technologyActive defense and two-way audioWaterproof IP67H.265+ compression technology
CAMERAImage sensor 1/3” CMOS with progressive scanShutter speed 1/3 to 1/10000 sSlow shutter Yes Minimum illumination 0.005 lux; 0 lux with IR/white lightDay/night mechanism IR Cut FilterDay/night switching unified/scheduled/automaticLENSLens type with fixed focusFocal length 2.8mm/4mm/6mmAperture 2.8mm: F1.64mm: F1.66mm: F1 .6FOV • 2.8mm:Horizontal field of view: 102.5°, Vertical field of view: 55.2°, Diagonal field of view: 122.1°• 4mm :Horizontal field of view: 76.3°, Vertical field of view: 40.6°, Diagonal field of view: 90.2°• 6mm:Horizontal field of view: 50.6 °, vertical viewing angle: 27.8°, diagonal viewing angle: 58.8°M12 lens mountDORI Distance • 2.8mmDetection: 64m (209ft) Note: 27m (87ft)Identify: 13m (42ft)Identification: 6m (21ft)• 4mmDetection: 80 m (262 ft)Note: 33 m (109 ft)Identify: 16 m (52 ??ft)Identify: 8 m (26 ft)• 6 mm Detect: 128 m (420 ft)Observe: 53 m (175 ft)Identify: 26 m (84 ft)Identify: 13 m (42 ft)ANGLE ADJUSTMENT (MANUAL)Range • Pan: 0° to 360°• Tilt: 0° to 90°• Rotate: 0° to 360 °ILLUMINATORIR LED • Quantity: 2• Range: 30m• Wavelength: 850nmWhite LED • Quantity: 2 • Range: 30mIlluminator on/off control Auto/Scheduled/Always on/Always offGENERALWorking temperature -30-60 °C Storage temperature -40-60°COperating humidity 95% or less (non-condensing)Storage humidity 95% or less (non-condensing)Package contents • Network camera VIGI• Quick start guide• Waterproof cable connectors• Mounting accessoriesMaterial PlasticNet weight 0.34 kgGross weight 0, 50 kgPower supply • 12V DC ± 5%, max. 7 W, 5.5 mm coaxial power plug• PoE: 802.3af/at, class 0, max. 8 WProtection IP67 WaterproofProduct dimensions (L x W x H) 78.5 × 188.0 × 71.5 mm (3.09 × 7.40 × 2.81 in)Certificates CE, NTRA, VCCI, BSMI, FCCVIDEOmax. Resolution 2560 X 1440Main Stream • Frame Rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps • Resolution:2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20 frames per second. br /Substream • Frame rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution :640x480, 352x288, 320x240• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20 frames per second.Bitrate control CBR, VBRVideo Compression • Mainstream: H.265+/H.265/H.264+/H.264• Substream: H.265/H.264High Profile H.264 H.264+ Mainstream SupportedH.265 Mainstream Type ProfileH.265+ Mainstream SupportedVideo Bitrate • Mainstream: 256Kbps to 4Mbps• Substream: 64 Kbps to 512 KbpsPICTUREPicture Settings• Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance• Avoid overexposure to infrared• HLC software adjustable client• Rotation (90°/270°)Image enhancement BLC/3D DNR/HLC/SmartIRWide dynamic range DWDRSNR ? 52 dBParameter switch images YesPrivacy mask Up to 4 masksROI 1 RegionOSD setting YesAUDIOAudio communication Two-way audio Audio Input YesAudio Output YesAudio Compression YesAudio Sampling Rate 8KHzEnvironmental Noise Filtering YesAudio Bitrate 64 Kbps (G.711 alaw)NETWORKProtocol • TCP/IP• UDP• ICMP• HTTP• HTTPS• DHCP, DNS, RTSP• NTP• UPnP• SSL/TLS• FTP/SFTP• RTP• IPv4• IPv6• ARPONVIF YesAPI Open Network Video Interface (Profile S)Simultaneous live viewing 3 main streams and 3 sub streamsClient application VIGI Security Manager VIGI Web User InterfaceWeb Browser • Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and aboveCloud YesSecurity Password protection, HTTPS encryption, IP address filter, Authentication checkALARM AND EVENT MANAGEMENTSmart event • Classification people and vehicles• Intrusion detection• Line crossing detection• Region entry detection• Region exit detection• Abandoned object detection• Detection object removal• Abnormal sound detection• People detection• Vehicle detectionBasic event • Motion detection• Video tampering detection• Exception (illegal login)Link to alarm • Video recording to memory card• Push messages• Sound warning• Flashing white lightConnection method N/A Output notification Push messageINTERFACESNetwork interface 1 RJ45 10/100M self-adaptive Ethernet port, PoEAlarm N/AReset button YesDC Power PortBuilt-in storage, built-in memory card slot, MicroSD card support, up to 512GB**Built-in microphone Yes; Records everything that happens within 15 ft of the cameraBuilt-in speaker YesNo audio available
