- 16× Full 10GE SFP+ Slots: Lightning-fast full 10 Gbps SFP+ slots provide high-bandwidth aggregation connectivity and non-blocking 320 Gbps switching capacity. Learn More about TP-Link 10G/Multi-Gigabit Switching Solutions
- Abundant L2 and L2+ Features: Supports a complete lineup of L2 and L2+ features including Static Routing, enterprise-level QoS, IGMP Snooping, and more.
- Robust Security Strategies: Helps protect LAN area investment with integrated IP-MAC-Port Binding, ACL, Port Security, 802.1X Authentication, and more.
- Dual Redundant Power Supplies: Two power supplies backing each other up make it an ideal choice for reliable networking architecture.
- Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management.
- Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities.

Specifications

HARDWARE FEATURES
- Interface:
* 16× 10GE SFP+ Slots
* 1× RJ45 Console Port
* 1× Micro-USB Console Port
- Fan Quantity: 1
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions ( W x D x H ): 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)
- Mounting: Rack Mountable
- Max Power Consumption: 32.74 W (220 V / 50 Hz)
- Max Heat Dissipation: 111.71 BTU/hr (220 V / 50 Hz)

PERFORMANCE
- Switching Capacity: 320 Gbps
- Packet Forwarding Rate: 238.08 Mpps
- MAC Address Table: 32 K
- Packet Buffer Memory: 24 Mbit
- Jumbo Frame: 9 KB

SOFTWARE FEATURES
Quality of Service:
* 8 priority queues
* 802.1p CoS/DSCP priority
* Queue scheduling
- SP (Strict Priority)
- WRR (Weighted Round Robin)
- SP+WRR
* Bandwidth Control
- Port/Flow based Rating Limiting
* Smoother Performance
* Action for Flows
- Mirror (to supported interface)
- Redirect (to supported interface)
- Rate Limit
- QoS Remark

L2 and L2+ Features
* Link Aggregation
- static link aggregation
- 802.3ad LACP
- Up to 8 aggregation groups, containing 8 ports per group
* Spanning Tree Protocol
- 802.1d STP
- 802.1w RSTP
- 802.1s MSTP
- STP Security: TC Protect, BPDU Filter, Root Protect
* Loopback Detection
- Port based
- VLAN based
* Flow Control
- 802.3x Flow Control
- HOL Blocking Prevention
* Mirroring
- Port Mirroring
- CPU Mirroring
- One-to-One
- Many-to-One
- Tx/Rx/Both

L2 Multicast
* IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
- IGMP Snooping Querier
- IGMP Authentication
* IGMP Authentication
* MLD Snooping
- MLD v1/v2 Snooping
- Fast Leave
- MLD Snooping Querier
- Static Group Config
- Limited IP Multicast
* MVR
* Multicast Filtering: 256 profiles and 16 entries per profile

VLAN
* VLAN Group
- Max 4K VLAN Groups
* 802.1Q Tagged VLAN
* MAC VLAN: 30 Entries
* Protocol VLAN: Protocol Template 16, Protocol VLAN 16
* Private VLAN
* GVRP
* VLAN VPN (QinQ)
- Port-Based QinQ
- Selective QinQ
* Voice VLAN

Access Control List
* Time-based ACL
* MAC ACL
- Source MAC
- Destination MAC
- VLAN ID
- User Priority
- Ether Type
* IP ACL
-Source IP
- Destination IP
- Fragment
- IP Protocol
- TCP Flag
- TCP/UDP Port
- DSCP/IP TOS
- User Priority
* Combined ACL
* Packet Content ACL
* IPv6 ACL
* Policy
- Mirroring
- Redirect
- Rate Limit
- QoS Remark
* ACL apply to Port/VLAN

Security
* IP-MAC-Port Binding
- 512 Entries
- DHCP Snooping
- ARP Inspection
- IPv4 Source Guard: 100 Entries
* IPv6-MAC-Port Binding
- 512 Entries
- DHCPv6 Snooping
- ND Detection
- IPv6 Source Guard: 100 Entries
* DoS Defend
* Static/Dynamic Port Security
- Up to 64 MAC addresses per port
* Broadcast/Multicast/Unicast Storm Control
- kbps/ratio control mode
* 802.1X
- Port base authentication
- Mac base authentication
- VLAN Assignment
- MAB
- Guest VLAN
- Support Radius authentication andaccountability
* AAA (including TACACS+)
* Port Isolation
* Secure web management through HTTPS with SSLv3/TLS 1.2
* Secure Command Line Interface (CLI) management with SSHv1/SSHv2
* IP/Port/MAC based access control

IPv6
* IPv6 Dual IPv4/IPv6
* Multicast Listener Discovery (MLD) Snooping
* IPv6 ACL
* IPv6 Interface
* Static IPv6 Routing
* IPv6 neighbor discovery (ND)
* Path maximum transmission unit (MTU) discovery
* Internet Control Message Protocol (ICMP) version 6
* TCPv6/UDPv6
* IPv6 applications
- DHCPv6 Client
- Ping6
- Tracert6
- Telnet (v6)
- IPv6 SNMP
- IPv6 SSH
- IPv6 SSL
- Http/Https
- IPv6 TFTP

L3 Features
* 16 IPv4/IPv6 Interfaces
* Static Routing
- 48 static routes
* Static ARP
- 128 Static Entries
* Proxy ARP
* Gratuitous ARP
* DHCP Server
* DHCP Relay
- DHCP Interface Relay
- DHCP VLAN Relay
* DHCP L2 Relay

Management
* Web-based GUI
* Command Line Interface (CLI) through the console port, telnet
* SNMP v1/v2c/v3
- Trap/Inform
- RMON (1,2,3,9 groups)
* SDM Template
* DHCP/BOOTP Client
* 802.1ab LLDP/LLDP-MED
* DHCP AutoInstall
* Dual Image, Dual Configuration
* CPU Monitoring
* Cable Diagnostics
* EEE
* Password Recovery
* SNTP
* System Log

Advanced Features
* Support Omada Hardware Controller (OC200/OC300), Software Controller, Cloud-Based Controller
* Automatic Device Discovery
* Batch Configuration
* Batch Firmware Upgrading
* Intelligent Network Monitoring
* Abnormal Event Warnings
* Unified Configuration
* Reboot Schedule
* ZTP (Zero-Touch Provisioning)

MIBs
* MIB II (RFC1213)
* Interface MIB (RFC2233)
* Ethernet Interface MIB (RFC1643)
* Bridge MIB (RFC1493)
* P/Q-Bridge MIB (RFC2674)
* RMON MIB (RFC2819)
* RMON2 MIB (RFC2021)
* Radius Accounting Client MIB (RFC2620)
* Radius Authentication Client MIB (RFC2618)
* Remote Ping, Traceroute MIB (RFC2925)
* Support TP-Link private MIB

MANAGEMENT
- Omada App: Yes/ Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller
- Centralized Management:
* Omada Cloud-Based Controller
* Omada Hardware Controller (OC300)
* Omada Hardware Controller (OC200)
* Omada Software Controller
- Cloud Access: Yes/ Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller
- Zero-Touch Provisioning: Yes/ Requiring the use of Omada Cloud-Based Controller.
- Management Features:
* Web-based GUI
* Command Line Interface (CLI) through the console port, telnet
* SNMP v1/v2c/v3
* Trap/Inform
* RMON (1,2,3,9 groups)
* SDM Template
* DHCP/BOOTP Client
* 802.1ab LLDP/LLDP-MED
* DHCP AutoInstall
* Dual Image, Dual Configuration
* CPU Monitoring
* Cable Diagnostics
* EEE
* Password Recovery
* SNTP
* System Log

OTHERS
- Certification:CE, FCC, RoHS
- Package Contents:
* TL-SX3016F Switch
* 2× Power Cords
* Quick Installation Guide
* Rackmount Kit
* Rubber Feet
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux
- Environment:
* Operating Temperature: 0–45 ? (32–113 ?);
* Storage Temperature: -40–70 ? (-40–158 ?)
* Operating Humidity: 10–90% RH non-condensing
* Storage Humidity: 5–90% RH non-condensing
