Two 2.5G ports: 1× 2.5G WAN and 1× 2.5G WAN/LAN port provide high-bandwidth aggregation connectivity.Up to 6 WAN ports: 2.5G RJ45 port, gigabit Fiber optic and Gigabit RJ45 WAN ports with load balancing maximize the utilization rate of multi-line broadband.Highly secure VPN: Enterprise-standard SSL/IPSec/GER§/PPTP/L2TP VPN and OpenVPN are ideal for multi-branch use and for WFH.Integrated into Omada SDN: Supports Zero-Touch Provisioning (ZTP),** Centralized Cloud Management, Intelligent Monitoring and more.Centralized Management: Cloud access and Omada app provide maximum convenience management.Extensive security features: Protect your network and data with advanced firewall policies, DoS defense, IP/MAC/URL filtering and more security features.
SECURITYAccess Control Source/Destination IP Based Access ControlFiltering • Web Group Filtering• URL Filtering• Web Security ARP inspection • Sending GARP packets• ARP scanning• IP-MAC bindingAttack protection • TCP/UDP/ICMP flood protection• Block TCP scanning (Stealth FIN/Xmas/Null)• Block Ping from WANHARDWARE FEATURESStandards and Protocols • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, IEEE802.3bz• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPNInterface • 1× 2.5G RJ45 WAN Port• 1× 2.5G RJ45 WAN/LAN Port• 1× Gigabit SFP WAN/LAN Port• 4 × gigabit port RJ45 WAN/LAN• 1× USB 2.0 port (supports USB memory and LTE backup with LTE dongle)Network media • 10BASE-T: UTP cable category 3, 4, 5 (max. 100 m) EIA/TIA-568 100? STP (max 100 m)• 100BASE-TX: Category 5, 5e UTP cable (max 100 m) EIA/TIA-568 100? STP (max 100 m)• 1000BASE-T: Category 5, 5e, 6 UTP cable (maximum 100 m)• 2500BASE-T: Category 5, 5e, 6 UTP cable (maximum 100 m)Quantity of fan Without fanButton Reset buttonPower supply 12V/1.5A adapterPoE budget -Flash 128MB NANDDRAM 1GB DDR4LED PWR, SYS, SFP , USB, WAN (Speed, Connection/Action), LAN (Speed, Connection/Action)Dimensions (W x D x H) 8.9 x 5.2 x 1.4 in (226 x 131 x 35 mm)Protection 4 kV surge protectionSteel housingMounting Desktop/wall mountingMaximum power consumption 14.2W (with USB2.0 connected)7, 1 W (without USB2.0 connected)PERFORMANCEIPS Throughput TCP: 208 Mbps;UDP: 161 MbpsDPI Throughput TCP: 1823 Mbps ;UDP: 1272 MbpsConcurrent session 500,000New sessions / other 6000NAT (static IP) 2365.17 Mbps / 2364.45 MbpsNAT(DHCP ) 2364.45 Mbps / 2366.04 MbpsNAT(PPPoE) 2347.14 Mbps / 2348.29 MbpsNAT (L2TP) 1308.86 Mbps / 974.10 MbpsNAT ( PPTP) 1236.27 Mbps / 1280.99 MbpsIPsec VPN Throughput • ESP-SHA1-AES256: 673.3 Mbps• ESP-SHA256-AES256: 650.2 Mb/s • ESP-SHA384-AES256: 629.3 Mb/s• ESP-SHA512-AES256: 633.8 Mb/sL2TP VPN Throughput • Unencrypted: 1243.7 Mbps• Encrypted : 561.0 Mb/sSSL VPN Throughput 132.24 Mbps66 Byte Packet Transfer Rate 1832.69 Mbps / 1741.84 Mbps1518 Byte Packet Transfer Rate 2461.18 Mbps / 2457.32 MbpsBASIC FUNCTIONSWAN Connection Type • IPv4_Static IP• IPv4_Dynamic IP• IPv4_PPPOE• IPv4_L2TP• IPv4_PPTP• IPv6_PPP• IPv6_DHCPv6• IPv6_Static IP• IPv6_6in4• IPv6_Pass-Through • Mobile broadband: 4G/3G modem for backup via USB portMAC Clone Modify WAN/LAN MAC Address†DHCP • DHCP server• DHCPv6 PD server (standalone mode only) • Customizing DHCP Options• DHCP Address Reservation• Multi-IP Interfaces*• Multi-Net DHCP*IPv6 StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Addressless ModeVLAN 802.1Q VLANIPTV IGMP v2/v3 Proxy, Custom Mode, Bridge ModeADVANCED FUNCTIONSAdvanced Routing • Static Routing• Routing Policy• RIP (standalone mode only)• OSPF (standalone mode only)Bandwidth Control • IP/Port Based Bandwidth Control • Warranty and Limited BandwidthLoad Balancing • Intelligent Load Balancing• Application Optimized Routing• Connection Backup (Time§, Failover)• Online discoveryNAT • One-to-one NAT§• Multi-Net NAT• Port Forwarding• Port Triggering§• NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG• UPnPSession Limit IP Based Session LimitVPNIPsec VPN • 100 IPSec VPN tunnels• LAN-to-LAN, Client-to-LAN• Main, aggressive negotiation mode• Encryption algorithm DES, 3DES, SHA1, AES128, AES192, AES256• IKEv1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 authentication algorithm• NAT Traversal (NAT-T)• Dead Peer Detection (DPD)• Perfect Forward Secrecy (PFS)PPTP VPN • PPTP VPN server• PPTP VPN clients (12)• 60 tunnels (shared with L2TP)• PPTP with MPPE encryptionL2TP VPN • L2TP VPN server• L2TP VPN clients (12)• 60 tunnels (shared with PPTP)• L2TP over IPSecOpenVPN • OpenVPN server• OpenVPN clients (6)• 66 OpenVPN tunnels*AUTHENTICATIONWeb authentication • No authentication• Simple password*• Hotspot (local user/Voucher* /SMS*/Radius*)• External radius server• External portal server*• LDAPMANAGEMENTOmada application Yes. Requires OC300, OC200, Omada Cloud-Based Controller or Omada Software Controller.Centralized Management • Omada Cloud Controller• Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200 )• Omada software controllerCloud access Yes. Requires use of OC300, OC200, Omada Cloud-Based Controller or Omada Software Controller.Dynamic DNS Service (Dyndns, No-IP, Peanuthull, Comexe)Maintenance • Web Management Interface• Remote management• Export and import configuration• SNMP v1/v2c/v3*• Diagnostics (Ping & Traceroute)§• NTP synchronization§• Port mirroring• CLI (standalone mode only)• Syslog supportNo touch enablement Yes. Requires the use of Omada Cloud Controller.Management Features • Automatic Device Discovery• Intelligent Network Monitoring• Abnormal Event Alerts• Unified Configuration• Reboot Schedule• Interception Portal Configuration• ZTP (Touchless Provisioning)OTHERCE, FCC, RoHS CertificationPackage Contents • ER707-M2• Charger• Quick Installation GuideSystem Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista ™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or LinuxEnvironment • Operating temperature: 0-40 ? (32-104 ?);• Storage temperature: -40- 70 ? (-40-158 ?)• Operating humidity: 10-90% RH non-condensing• Storage humidity: 5-90% non-condensing
