2.5G ports for WiFi 7/6E/6: 8× 2.5 Gbps PoE+ ports and 8× 2.5 Gbps Non-PoE ports break the 2.5G barrier and unlock the full potential of WiFi 7/6E/6 AP.10G Lightning Fast Uplink: 2 × 10 Gbps SFP+ slots provide high-bandwidth connectivity and non-blocking switching performance.240W PoE budget: 8 × 802.3at/af-compatible PoE+ ports with a total power of 240W*.Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, centralized cloud management and intelligent monitoring.Centralized management: cloud access and Omada application for extreme convenience and easy management.Static Routing: Helps route internal traffic for more efficient use of network resources.Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Protection, Storm Control, DHCP Snooping, 802.1X, Radio Authentication and more.Optimize voice and video applications: L2/L3/L4 QoS and IGMP snooping.
HARDWARE FEATURESInterface • 16× 2.5 Gbps RJ45 ports• 2× 10G SFP+ slots• 1× RJ45 console port• 1 × Micro-USB console portFan quantity 2Power supply 100-240 V AC~50/60 HzPoE port (RJ45) • Standard: 802.3at/af compliant • PoE+ (802.3at PoE) ports: 8 ports, up to 30 W per port• Power budget: 240 WDimensions (W x D x H) 17.3 x 7.1 × 1.7 in (440 × 180 × 44 mm)Rack MountMax Power Consumption 299.4 W (110 V/60 Hz) (with 240 W PD connected)Max heat dissipation 1021.64 BTU/h (110 V/60 Hz) (with 240 W PD connected)PERFORMANCESwitching capacity 120 GbpsPacket forwarding rate 89 .28 MppsMAC Address Table 16 KPacket Buffer 12 MbitJumbo Frame 9 KBSOFTWARE FEATURESQuality of Service • 8 priority queues• 802.1p CoS/DSCP priority• Queue scheduling- SP (strict priority)- WRR (weighted round robin)- SP+ WRR• Bandwidth Control- Port/Flow Based Rating Limit• Smoother Operation• Flow Measure: QoS Annotation (802.1P Annotation, DSCP Annotation)L3 Features • 32 IPv4/IPv6 Interfaces• Static Routing- 48 Static Routes• Static ARP- 128 Static Entries• Proxy ARP• Free ARP• DHCP Server• DHCP Relay- DHCP Interface Relay- DHCP VLAN Relay• DHCP L2 RelayL2 and L2+ Features • Link Aggregation- static link aggregation- 802.3ad LACP- Up to 8 aggregation groups containing 8 ports per group• Spanning Tree Protocol- 802.1d STP- 802.1w RSTP- 802.1s MSTP- STP Security: TC Protect, BPDU Filter, Root Protect• Loopback Detection- Port Based br /- VLAN based• Flow control- 802.3x flow control- HOL blocking prevention• Mirroring- Port mirroring- Mirroring of processors- One to one- Many to one- Tx/Rx/bothL2 Multicast • IGMP Snooping- Snooping IGMP v1/v2/v3- Fast Departure- IGMP Snooping Querier- IGMP Authentication• IGMP Authentication• MLD Snooping- MLD v1/v2 Snooping- Quick Departure- MLD Snooping Querier- Static Group Configuration- Limited IP Multicast• MVR• Multicast Filtering: 256 profiles and 16 entries per profileAdvanced Features • Automatic Device Discovery• Batch Configuration• Batch Firmware Upgradeequipment• Intelligent network monitoring• Abnormal event alerts• Unified configuration• Reboot scheduleVLAN • VLAN group- Maximum 4K groups VLAN• 802.1Q tagged VLAN• MAC VLAN: 256 entries• Protocol VLAN: Protocol Template 16, Protocol VLAN 16• GVRP• VLAN VPN (QinQ )- Port Based QinQ- Selective QinQ• Voice VLANAccess Control List • Time Based ACL• MAC ACL- MAC Origin - MAC Destination- VLAN ID- User Priority- Ether Type• IP ACL- Source IP- Destination IP br /- Bit- IP Protocol- TCP Flag- TCP/UDP Port- TOS DSCP/IP- User Priority• Combined ACL• Packet Content ACL• IPv6 ACL• Policy- Mirroring- Redirect- Rate Limiting- QoS Note• ACL applies to ports/VLANsSecurity • IP-MAC-Port Binding- 512 entries- DHCP Snooping- ARP Inspection- IPv4 Source Guard : 100 entries• IPv6-MAC-Port Binding- 512 entries- DHCPv6 Snooping- ND Detection- IPv6 Source Guard: 100 entries • DoS protection• Static/dynamic port security- Up to 64 MAC addresses per port• Broadcast/Multicast/Unicast Storm Control- kbps/rate control mode • 802.1X- Basic Port Authentication- Basic Mac Authentication- VLAN Assignment- MAB- Guest VLAN- Supports Radius Authentication and Accountability • AAA (including TACACS+)• Port isolation• Secure web management over HTTPS with SSLv3/TLS 1.2• Secure command line interface (CLI) management with SSHv1/SSHv2 • IP/Port/MAC Based Access ControlIPv6 • IPv6 Dual IPv4/IPv6• Multicast Listener Discovery (MLD) Snooping.• IPv6 ACL• IPv6 Interface• IPv6 Static Routing• IPv6 Neighbor Discovery (ND)• Maximum Transmission Unit (MTU) Discovery.• Internet Control Message Protocol (ICMP), version 6• TCPv6/UDPv6• IPv6 Applications- DHCPv6 Client- Ping6- Tracert6- Telnet (v6)- IPv6 SNMP- IPv6 SSH- IPv6 SSL- Http/Https- IPv6 TFTPMIBs • MIB II (RFC1213)• Interface MIB (RFC2233)• Ethernet Interface MIB (RFC1643)• Bridge MIB (RFC1493)• P/Q-Bridge MIB (RFC2674)• RMON MIB (RFC2819)• RMON2 MIB (RFC2021)• Radius Accounting Client MIB (RFC2620)• Radius Authentication Client MIB (RFC2618)• Remote Ping, Traceroute MIB (RFC2925) • Supports TP-Link Private MIBMANAGEMENTOmada App Yes. Requires OC300, OC200, Omada Cloud-Based Controller or Omada Software Controller.Centralized Management • Omada Cloud Controller• Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200 )• Omada software controllerCloud access Yes. Requires use of OC300, OC200, Omada Cloud-Based Controller or Omada Software Controller.Touchless Enablement Yes. Requires use of Omada Cloud Controller.Management Features • Web GUI• Command Line Interface (CLI) via console port, telnet• SNMP v1/v2c/v3- Trap/ Inform- RMON (1,2,3,9 Groups)• SDM Template• DHCP/BOOTP Client• 802.1ab LLDP/LLDP-MED• DHCP Auto Setup• Dual Image, Dual Configuration• CPU Monitoring• Cable Diagnostics• EEE• Obnpassword wrapper• SNTP System Log• System LogOTHERSCE, FCC, RoHS CertificationPackage Contents • SG3218XP-M2 Switch• Power Cord• Quick Installation Guide• Rack Mount Kit• Rubber FeetSystem Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.Environment • Operating Temperature: 0-50? (32-122?);• Temperature storage: -40-70? (-40-158?)• Operating humidity: 10-90% RH non-condensing• Storage humidity: 5-90% RH non-condensing
