Hardware Specifications
CPU
- CPU Model: Intel Atom C2538
- CPU Frequency: Quad Core 2.4 GHz
- Floating Point: Yes
- Hardware Encryption Acceleration (AES-NI): Yes
MEMORY
- System Memory: 2 GB DDR3
- Memory Module Pre-installed: 2 GB ×1
- Total Memory Slots: 2
- Memory Expandable up to: 6 GB (2 GB + 4 GB)
STORAGE
- Drive Bay(s): 5
- max. Drive Bays with Expansion Unit: 15
- Compatible Drive Type:
* 3.5" SATA(III) / SATA(II) HDD
* 2.5" SATA(III) / SATA(II) HDD
* 2.5" SATA(III) / SATA(II) SSD
- max. Internal Raw Capacity: 30 TB (6 TB HDD X 5) (Capacity may vary by RAID types)
- Hot Swappable Drive: Yes
EXTERNAL PORTS
- USB 3.0 Port ×4
- eSATA Port ×2
FILE SYSTEM
- Internal Drives: EXT4
- External Drives: EXT4, EXT3, FAT, NTFS, HFS+
APPEARANCE
- Size (H×W×D): 157×248×233 mm
- Weight: 4.17 kg
OTHERS
- RJ-45 1GbE LAN Port: 4 (with Link Aggregation / Failover support)
- Wake on LAN/WAN: Yes
- System Fan: 80×80 mm ×2 pcs
- Easy Replacement System Fan: Yes
- Wireless Support (dongle): Yes
- Noise Level: 22.3 dB(A)
- Power Recovery: Yes
- Scheduled Power On/Off: Yes
- Power Supply Unit / Adapter: 250W
- AC Input Power Voltage: 100V to 240V AC
- Power Frequency: 50/60 HZ, Single Phase
- Power Consumption:
* 38.39W (Access)
* 21.63W (HDD Hibernation)
TEMPERATURE
- Operating Temperature: 5C to 35C (40F to 95F)
- Storage Temperature: -20C to 60C (-5F to 140F)
- Relative Humidity: 5% to 95% RH

DSM Specifications
STORAGE MANAGEMENT
- max. Single Volume Size: 108 TB
- max. Internal Volume Number: 512
- max. iSCSI Target Number: 32
- max. iSCSI LUN: 256
- iSCSI LUN Clone/Snapshot, Windows ODX: Yes
- Supported RAID Type: Synology Hybrid RAID, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
- RAID Migration: Basic to RAID 1, Basic to RAID 5, RAID 1 to RAID 5, RAID 5 to RAID 6
- Volume Expansion with Larger HDDs: Synology Hybrid RAID, RAID 1, RAID 5, RAID 6
- Volume Expansion by Adding a HDD: Synology Hybrid RAID, RAID 5, RAID 6, JBOD
- Global Hot Spare Supported RAID Type: Synology Hybrid RAID, RAID 1, RAID 5, RAID 6, RAID 10
SSD SUPPORT
- SSD Read/Write Cache (White Paper): Yes
- SSD TRIM: Yes
FILE SHARING CAPACITY
- max. User Accounts: 2048
- max. Groups: 256
- max. Shared Folder: 512
- max. Shared Folder Sync Tasks: 8
- max. Concurrent CIFS/AFP/FTP Connections: 512
- Windows Access Control List (ACL) Integration: Yes
- NFS Kerberos Authentication: Yes
- High Availability Manager: Yes
- Log Center: Yes
- Syslog Events per Second: 800
VIRTUALIZATION
- VMware vSphere 5 with VAAI: Yes
- Windows Server 2012: Yes
- Windows Server 2012 R2: Yes
- Citrix Ready: Yes

Add-on Packages
- Antivirus Essential: Yes
- Antivirus by McAfee (Trial): Yes
- Audio Station: Yes
- Central Management System: Yes
- Cloud Station: Yes
- max. Concurrent File Transfers: 512
- Cloud Sync: Yes
- Directory Server: Yes
- DNS Server: Yes
- Download Station: Yes
- max. Concurrent Download Tasks: 80
- Glacier Backup: Yes
- HiDrive Backup: Yes
- iTunes Server: Yes
- Java Manager: Yes
- Mail Server: Yes
- Mail Station: Yes
- Media Server: Yes
- DLNA Certification: Yes
- Photo Station: Yes
- RADIUS Server: Yes
- Surveillance Station: Yes
- max. IP cam (Licenses required): 40 (including 2 Free License)
- Total FPS (H.264):
* 1200 FPS @ 720p (1280×800)
* 480 FPS @ 1080p (1920×1080)
* 250 FPS @ 3M (2048×1536)
* 200 FPS @ 5M (2591×1944)
- Total FPS (MJPEG):
* 300 FPS @ 720p (1280×800)
* 150 FPS @ 1080p (1920×1080)
* 100 FPS @ 3M (2048×1536)
* 60 FPS @ 5M (2591×1944)
- Time Backup: Yes
- max. Task Number: 8
- Video Station: Yes
- Video Transcoding: Group 1
- VPN Server: Yes
- max. Connections: 20

Environment & Packaging
- Packaging Content:
1× Main Unit
1× Welcome Note
1× Accessory Pack
1× AC Power Cord
2× RJ-45 LAN Cable
- Optional Accessories: Remote, Camera License Pack, 4GB DDR3 RAM Module, Expansion Unit: DX213 ×2, Expansion Unit: DX513 ×2, VS240HD
