Key Features
- Cost-Effective VDSL2 Profile 17a/30a CO / CPE bridge solution
- One box design, CO / CPE selectable via DIP Switch
- Defines symmetric band plan for the transmission of upstream and downstream signals
- Complies with IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX and IEEE 802.3x, Flow control Ethernet standards
- DMT (Discrete Multi-Tone) line coding
- Half duplex Back pressure and IEEE 802.3x Full Duplex Pause frame flow control
- Built-in POTS splitter to share voice and data
- Two RJ-11 connectors for each VDSL port, one for VDSL connection and one for POST connection
- Voice and data communication can be shared simultaneously based on the existing telephone wire
- Four 10/100Mbps RJ-45 port, Auto-Negotiation and Auto-MDI/MDI-X
- Supports up to 1536 bytes packet size, IEEE 802.1Q VLAN tag transparent
- Hardware IGMP Snooping for Multimedia service
- VDSL2 stand-alone transceiver for simple bridge modem application
- Advantage of minimum installation time (Simply as Plug-and-Play)
- Selectable target profile and target SNR margin
- Supports extensive LED indicators for network diagnosis

Specification
HARDWARE SPECIFICATION
- Ports:
* 10/100Base-TX: 4 RJ-45, Auto-Negotiation and Auto-MDI/MDI-X
* VDSL: 1 RJ-11, female Phone Jack
* PHONE: 1 RJ-11, Built-in splitters for POTS connection
- DIP Switch: 4 position DIP switch
- Functionality:
* CO / CPE mode select
* Selectable fast and interleaved mode
* Selectable target 17a / 30a profiles
* Selectable target SNR mode
- Encoding: VDSL-DMT (ITU-T G.993.1 VDSL; ITU-T G.997.1; ITU-T G.993.2 VDSL2 (Profile 17a/30a Support)
- LED Indicators:
* One Power
* 4 for RJ-11/VDSL2
* 1 for per RJ-45 10/100Base-TX port
- Cabling:
* Ethernet: 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft); 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)
* VDSL: Twisted-pair telephone wires (AWG24 or better) up to 1.4km
- Performance (Downstream / Upstream):
* 17a profile
300m -> 99/70Mbps
400m -> 99/60Mbps
600m -> 90/45Mbps
800m -> 50/28Mbps
1000m -> 40/12Mbps
1200m -> 20/7Mbps
1400m -> 20/4Mbps
* 30a profile
300m -> 100/100Mbps
400m -> 90/90Mbps
600m -> 69/55Mbps
800m -> 48/9Mbps
- Power Requirement: 5V DC, 2A
- Power Consumption: 7.2 Watts/ 24 BTU
- Dimension (W×D×H): 155×86×26 mm
- Weight: 368g

ENVIRONMENT
- Operating:
* Temperature: 0 - 50 Degree C
* Relative Humidity: 10 - 90% (non-condensing)
- Storage:
* Temperature: -10 - 70 Degree C
* Relative Humidity: 10 - 90% (non-condensing)

SWITCH SPECIFICATION
- Switch Processing Scheme: Store-and-Forward
- Address Table: 2K entries
- Flow Control: Back pressure for half duplex; IEEE 802.3x Pause Frame for full duplex
- Switch fabric: 0.8Gbps
- Throughput (packet per second): 0.59Mpps
- Network cables:
* 10/100Base-TX:
* 2-Pair UTP Cat. 3,4, 5 (100meters, max.)
* EIA / TIA-568 100-ohm STP (100meters, max.)

STANDARD CONFORMANCE
- Regulation Compliance: FCC Part 15 Class A, CE
- Standards Compliance:
* IEEE 802.3 10Base-T
* IEEE 802.3u 100Base-TX
* ITU-T:
G.993.1 (VDSL)
G.997.1
G.993.2 VDSL2 (Profile 17a/30a)
