SPECIFICATIONS
CPU
- LGA 775 socket for: Intel CoreTM2 Quad and Intel CoreTM2 Duo
- Supports Intel Enhanced Memory 64 Technology (EMT64T)
- Supports Enhanced Intel SpeedStep Technology (EIST)
- Supports Intel Hyper-Threading Technology
- Supports 1333*/1066/800MHz system bus speed (*Available only on CPUs that support 1333MHz FSB)

CHIPSET
- Intel chipset: Northbridge: Intel X38 Express chipset (with Intel Fast Memory Access technology)

SYSTEM MEMORY
- Four 240-pin DDR2 DIMM sockets
- Supports DDR2 1066MHz (O.C 1200MHz)
- Delivers up to 12.8Gb/s bandwidth
- Supports dual channel (128-bit wide) memory interface
- Supports up to 8GB system memory
- Supports unbuffered x8 and x16 DIMMs

EXPANSION SLOTS
- 2 PCI Express (Gen 2) x16 slots (PCIE 1 and PCIE 3) - 2-way CrossFire at x16/x16 bandwidth
- 1 PCI Express x4 slot (PCIE 2)
- 3 PCI slots

BIOS
- Award BIOS
- 8Mbit flash memory
- CMOS Reloaded

AUDIO
- Realtek ALC885 High Definition audio CODEC
- 8-channel audio output
- DAC SNR/ADC SNR of 106dB/101dB
- Full-rate lossless content protection technology
- Optical S/PDIF-out and coaxial RCA S/PDIF-out interfaces

LAN
- Marvell 88E8053 PCIE Gigabit LAN controller
- Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX) and 802.3ab (1000BASE-T) standards

Serial ATA with RAID
- Intel Matrix Storage technology
- Supports up to 6 SATA devices
- SATA speed up to 3Gb/s
- RAID 0, RAID 1, RAID 0+1 and RAID

IDE
- JMicron JMB368 PCI Express to PATA host controller
- Supports up to 2 UltraDMA 33/66/100Mbps IDE devices

REAR PANEL I/O
- 1 mini-DIN-6 PS/2 mouse port
- 1 mini-DIN-6 PS/2 keyboard port
- 1 optical S/PDIF-out port
- 1 coaxial RCA S/PDIF-out port
- 6 USB 2.0/1.1 ports
- 1 RJ45 LAN port
- Center/subwoofer, rear R/L and side R/L jacks
- Line-in, line-out (front R/L) and mic-in jacks

INTERNAL I/O
- 3 connectors for 6 additional external USB 2.0 ports
- 1 connector for an external COM port
- 1 front audio connector
- 1 CD-in connector
- 1 IrDA connector
- 6 Serial ATA connectors
- 1 40-pin IDE connector
- 1 floppy connector
- 1 24-pin ATX power connector
- 1 8-pin 12V power connector
- 2 4-pin 5V/12V power connectors (FDD type)
- 1 front panel connector
- 6 fan connectors
- 1 download flash BIOS connector
- 1 diagnostic LED
- EZ touch switches (power switch and reset switch)

POWER MANAGEMENT
- Ultimate 4-phase digital PWM with 12 MOSFETs
- ACPI and OS Directed Power Management
- ACPI STR (Suspend to RAM) function
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
- AC power failure recovery

HARDWARE MONITOR
- Monitors CPU/system/Northbridge temperature and overheat alarm
- Monitors Vcore/Vdimm/Vnb/VCC5/12V/V5sb/Vbat voltages
- Monitors the speed of the cooling fans
- CPU Overheat Protection function monitors CPU temperature and fan during system boot-up - automatic shutdown upon system overheat

PCB
- 6 layers, ATX form factor
- 24.5×30.5 cm
