The Features of the Lian Li O11 Dynamic Mini Snow Edition Mid-Tower at a Glance:

Extremely versatile case with a modular back panel
Accommodates motherboards with an ATX, Micro-ATX or Mini-ITX form factor
Front and left side panel from tempered glass
Roof and right side panel made of aluminium
I/O panel with one USB-C and two USB 3.0 ports
Support for graphics cards up to 395 in length
Up to nine 120mm fans possible
Suitable for SFX and SFX-L power supplies
Including three modular pump stands for easy mounting

O11 Dynamic Mini Snow Edition: Modular PC Case with a Stylish Design
The Lian Li O11 Dynamic Mini Snow Edition is extremely versatile thanks to its modular back panel. The scope of delivery contains various brackets that can be used to adjust the rear panel. This greatly affects the choice of components. The smaller the motherboard, the more space is available for other components.
7 Slots
When the rear panel is in its seven slot configuration, an ATX motherboard can be installed. Radiators cannot be attached to the top, but it is possible to mount fans there instead. However, you can fit one radiator right next to the motherboard and mount a second one to the bottom of the case.

Motherboards: ATX, Micro-ATX, Mini-ITX
Expansion slots: 7
Roof: 120 or 140mm fans (up to 25mm thick)
Side: 280mm radiator up to 65mm thick or 240mm radiator up to 85mm thick
Bottom (ATX): Max. 360 radiator or 120mm fans
Bottom (Micro-ATX/Mini-ITX): Max. 360/280 radiator or 140mm fans

5 Slots
When the rear panel has been configured for five expansion slots, it is possible to install motherboards up to Micro-ATX form factor. The motherboard is mounted in a lower position, so that a radiator can be mounted to the top.

Motherboards: Micro-ATX, Mini-ITX
Expansion slots: 5
Roof: Max. 360 or 280 radiator (up to 65mm)
Side: 280mm radiator up to 65mm thick or 240mm radiator up to 85mm thick
Bottom (Micro-ATX): Max. a 360 radiator or 120mm fans
Bottom (Mini-ITX): Max. a 360 or 280mm radiator or 140mm fans

3 Slots
When the rear panel has been set to three expansion slots there is room for virtually any graphics card to be installed with the Mini-ITX motherboard. Even the largest radiators can be mounted above and below the motherboard in this configuration.

Motherboards: Mini-ITX only
Expansion slots: 3
Roof: Max. 360 or 280 radiators (up to 100mm)
Side: 280mm radiator up to 65mm thick or 240mm radiator up to 85mm thick
Bottom: Max. 360/280mm radiator (up to 75mm thick) or 140mm fans

Room for a Powerful Gaming System
A 120mm fan can be mounted to the rear panel. The air inlets at the bottom, top, and side are equipped with magnetic dust filters, so the interior remains clean. The Lian Li O11 Dynamic Mini Snow Edition accommodates CPU coolers up to 170mm in height, so that there are practically no limits when choosing a powerful processor cooler. This case also supports particularly large graphics cards up to 395mm in length.
Hard Drives and SSDs
The power supply unit and the drives are housed in the right chamber of the O11 Dynamic Mini Snow Edition. The case supports SFX and SFX-L form factor power supplies and offers bays for a total of four drives:

2x 3.5/2.5" and 2x 2.5"

Design, Materials and Connectivity
The Lian Li O11 Dynamic Mini Snow Edition has the same distinctive, stylish design that makes the O11 series so popular. The case is based upon a sturdy steel frame. The top and the right side panel are made of white powder coated aluminium. The left side panel and the front panel are made of 4mm thick, tinted tempered glass, so that you can showcase your hardware. A white powdered aluminium moulding adorns the right side of the front. The ports and buttons integrated into the top of the Lian Li O11 Dynamic Mini Snow Edition are easily accessible:

2x USB 3.0 type-A
1x USB 3.1 type-C
1x 3.5mm audio jack (4-pole)
Power button with integrated HDD LED
