Measurement:
Current Range to 30A/300A/3000A AC ±3%+5
Minimum Resolution: 0.01A
Frequency Range 45Hz~500Hz
Cable Length:18“ ( 45.72cm )

Main Features:
True RMS response
Inrush current measurement
Display backlight
CAT IV 600V, CAT III 1000V
IP54
2m drop proof
ETL/Intertek Certified 3rd edition CE

Basic Functions Range Basic Accuracy
Model UT281C
Max current measurement (AC) 0.00A ~ 3000A ±(3%+5)
Current measurement (AC) 0.00A ~ 30.00A ±(3%+5)
Current measurement (AC) 0.0A ~ 300.0A ±(3%+5)
Current measurement (AC) 0A ~ 3000A ±(3%+5)
Inrush current measurement 0.00A ~ 3000A For reference
Frequency response 45Hz~500Hz (sine wave) ?
Jaw size Rogowski flex coil (diameter: 8mm) Bending length: 18 inches (45.7cm); radius: around 3.1 inches (8cm)
True RMS measurement ?
Measuring digit conversion rate times/s 3
LCD display (TN) interface Single display
Manual range ?
Auto power off ?
Buzzer ?
Low battery indication ?
Data hold ?
Manual backlight ?
Working temperature 0°C ~ 50°C
2m drop proof ?
Protection grade IP54
Safety certification grade CAT IV 600V

General features
Device color Red and grey
Device weight 236g
Device size 350mm × 190mm × 55mm
Standard individual packing Gift box, blister, English manual
