DIGITALNI VIDEO SNIMAČ iDS-7316HUHI-M4/S


  large-image
DIGITALNI VIDEO SNIMAČ iDS-7316HUHI-M4/S
Kliknite na sliku za povećanje
thumb thumb
Proizvođač: Hikvision
Šifra: 1413686
Kataloški broj:
Jamstvo: 12
Raspoloživost: Dobavljivo (Dobavljivo)
Prosječna ocjena: Ocjena 0 0,00 | Glasova: 0
  Ocijeni ovaj proizvod

1.156,10 €

Načini plaćanja online

Popust 10%
1.156,10 €

Transakcijski račun
Popust 9%
1.168,95 €

Kriptovalute
Popust 8%
1.181,79 €

Maestro, MasterCard, Visa
Popust 6%
1.207,48 €

Union, PBZ Maestro/Visa Inspire 2-6 rata
Popust 5%
1.220,33 €

Diners, ZABA Master/Visa 2-6 rata, ERSTE Master/Visa/Maestro 2-6 rata
Popust 4%
1.233,17 €

Diners 2-12 rata, PBZ Visa Inspire/Maestro 7-12 rata, PBZ Visa Premium 2-6 rata
Popust 3%
1.246,02 €

ZABA Master/Visa 7-12 rata
Popust 2%
1.258,86 €

ERSTE Master/Visa/Maestro 2-6 rata, PBZ Visa Premium 7-12 rata
Popust se ne obračunava
1.284,56 €

ZABA Master/Visa 13-24 rate, Diners 13-24 rate

Načini plaćanja u trgovini

Popust 10%
1.156,10 €

Novčanice, Transakcijski račun
Popust 9%
1.168,95 €

Maestro, MasterCard, Visa
Popust 7%
1.194,64 €

PBZ Maestro/Visa Inspire 2-6 rata
Popust 6%
1.207,48 €

RBA Master/Visa 2-12 rata
Popust 5%
1.220,33 €

Diners, ZABA kartice 2-6 rata, Diners 2-6 rata, ERSTE Maestro/Visa/Master 2-8 rata, PBZ Maestro/Visa Inspire 7-12 rata
Popust 4%
1.233,17 €

ZABA Master/Visa 7-12 rata, Diners 7-12 rata, PBZ Visa Premium 2-6 rata
Popust 3%
1.246,02 €

ERSTE Maestro/Visa/Master 9-12 rata
Popust 2%
1.258,86 €

Diners 13-24 rate, PBZ Visa Premium 7-12 rata
Popust se ne obračunava
1.284,56 €

ZABA Maestro/Visa 7-12 rata, ZABA Visa 13-24 rate, ZABA Master 13-36 rata, Diners 25-36 rata

*MBNET kartice (Maestro, Visa, Mastercard) kojima je moguće plaćanje na rate izdane od Slatinske banke, Istarske kreditne banke, Sberbanke, KentBank i Agram banke
**kod nonSEPA transakcija naplaćujemo naknadu banke

već od 35,68 €/mjesečno

Odabrali ste prikaz cijena za gotovinsko plaćanje - prikaži MPC



DIGITALNI VIDEO SNIMAČ iDS-7316HUHI-M4/S

Glavne karakteristike

  • REALTIME 1080P

  • analogne, AHD, CVI i HD-TVI

  • HDMI & VGA, CVBS izlaz,

STANDARDNI MOD

16 HD/CVBS KAMERE (do 8MP) + 8IP ili 34 IP KAMERA (do 12MP)

ENHANCED IP MOD



ANALOGNI I HD-TVI/CVI Video

ulaz

8kanala, BNC sučelje (1.0Vp-p, 75 )

Video kompresija

H.265 Pro+/H.265 Pro/H.265/ H.264+/H.264

Sinkronizirani playback

16ch

Playback rezolucija

8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50,

720p30, 720p25

VGA/HDMI izlaz

VGA I HDMI1: 1-ch, 1920 ×1080/60Hz, 1280 ×1024/60Hz, 1280 ×720/60Hz, 1024 × 768/60Hz

HDMI2: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Main stream

8MP@8fps,5 MP@12fps, 4MP@15fps, 3 MP@18fps /1080p/ 720p/ WD1/4CIF/VGA/CIF@25fps (P)/30fps

Sub-stream

WD1/4CIF/CIF@25fps(P)/30fps(N)

Video Bit Rate

32Kbps ~ 10Mbps

Audio kompresija

G.711u

Audio ulaz / audio ulaz dvosmjerni

4 kanal RCA (2.0Vp-p, 1K )

Audio izlaz

2 kanala RCA (linearni, 1k )

Sučelje

SATA x 4

Kapacitet

do 12 TB po svakom disku

Sučelje za komunikaciju

2 x RJ45 10M/100M/1000M Ethernet Port 1 x RS-485 Port, 1 x eSATA, 1x RS232

USB sučelje

2x USB 2.0, 1x USB 3.0

Napajanje

12VDC 5A

Potrošnja struje

≤40W (bezHDD)

Radna temperatura

-10°C ~ 55°C

Masa

7KG

Dimenzije

445 × 400 × 71 mm

Alarm ulaz/izlaz

16/4

Za odabrani proizvod nije definirana specifikacija.

Za odabrani proizvod nije unesen niti jedan komentar.
