The Features of the Lian Li O11 Air Mini Mid-Tower at a Glance:

Extremely versatile case with a modular back panel
Accommodates motherboards with an E-ATX, ATX, Micro-ATX or Mini-ITX form factor
Tinted tempered glass side panel to showcase your hardware
Top, front and right side panel made of aluminium
I/O panel with one USB-C and two USB 3.0 ports
Support for high-end graphics cards up to 362 mm in length
Up to ten 120 mm fans possible for maximised cooling
Suitable for full-size ATX power supplies to satisfy power-hungry hardware
Including three PWM fans for efficient cooling out of the box

O11 Air Mini: Modular PC Case with Excellent Airflow
The Lian Li O11 Air Mini is extremely versatile thanks to its modular back panel. The scope of delivery contains various brackets that can be used to adjust the rear panel. This greatly affects the choice of components. The smaller the motherboard, the more space is available for other components.
7-Slot Rear Panel Configuration
When the rear panel is in its seven slot configuration, an ATX motherboard can be installed. Radiators cannot be attached to the top, but it is possible to mount fans there instead. However, you can fit one radiator right next to the motherboard, mount one to the front, and one to the bottom of the case. Sacrificing the side radiator, you'll be able to install an E-ATX motherboard that is up to 280 mm in width.

Motherboards: E-ATX (without side radiator), ATX, Micro-ATX, Mini-ITX
Expansion slots: 7
Top: Three 120 or two 140 mm fans (up to 25 mm thick)
Side: 240 mm radiator up to 59 mm thick
Front: Max. 240 / 280 mm radiator or two 120 / 140 mm fans
Bottom (ATX): max. 240 radiator or two 140 mm fans
Bottom (Micro-ATX / Mini-ITX): max. 240 or 280 radiator or two 120 / 140 mm fans

5-Slot Rear Panel Configuration
When the rear panel has been configured for five expansion slots, it is possible to install motherboards up to Micro-ATX form factor. The motherboard is mounted in a lower position so that a radiator can be mounted to the top.

Motherboards: Micro-ATX, Mini-ITX
Expansion slots: 5
Top: Max. 240 / 280 mm radiator (up to 65 mm)
Side: 240 mm radiator up to 59 mm thick
Front: Max. 240 / 280 mm radiator or 2x 120 / 140 mm fans
Bottom (Micro-ATX): max. 240 radiator or 2x 120 / 140 mm fans
Bottom (Mini-ITX): max. 240 or 280 mm radiator or 2x 120 / 140 mm fans

Room for a Powerful Gaming System
An additional 120 mm fan can be mounted to the rear panel in all possible configurations. Super-fine ventilation openings at the front, top, and side panels allow for excellent airflow. The Lian Li O11 Air Mini accommodates CPU coolers up to 170 mm in height so that there are practically no limits when choosing a powerful processor cooler. This case also supports particularly large graphics cards up to 362 mm in length.
Hard Drives and SSDs
The power supply unit and the drives are housed in the right chamber of the O11 Air Mini. The case supports ATX form factor power supplies up to 200 mm in length and offers mounting slots for a total of six drives:

4x 3.5/2.5" and 2x 2.5"

Design, Materials and Connectivity
The Lian Li O11 Air Mini has a functional, yet distinctive and stylish design. The case is based upon a sturdy steel frame. The top, the front and the right side panel are made of black anodized, brushed aluminium. The left side panel is made of 4 mm thick, tinted tempered glass, so that you can showcase your hardware. The ports and buttons integrated into the top panel of the Lian Li O11 Air Mini are easily accessible:

2x USB 3.0 type A
1x USB 3.1 type C
1x 3.5 mm audio jack (4-pole)
Power button with integrated HDD LED

Technical Details:

Dimensions: 288 x 384 x 400 mm (W x H x D)
Materials: steel, aluminium, tempered glass
Weight: 8.5 kg
Colour: black
Form factor: E-ATX (up to 280 mm wide), ATX, Micro-ATX, Mini-ITX
Total fans possible:

2x 120 / 140 mm (front)
3x 120 / 2x 140 mm (top)
2x 120 / 140 mm (side)
2x 120 / 140 mm (bottom)
1x 120 mm (rear)


Radiator-Mountings:

1x max. 240 / 280 mm (front)
1x max. 240 / 280 mm (top)
1x max. 240 mm (side)
1x max. 240 / 280 mm (bottom)


Dust filters: bottom (slide-in)
Drive bays:

4x 3.5/2.5" (internal)
2x 2.5" (internal)


PSU support: 1x ATX (optional)
Expansion slots: 7 / 5 (depending on the rear panel)
I/O panel:

1x USB 3.1 type C (internal connector)
2x USB 3.0 type A (internal connector)
1x 3.5 mm combo audio jack (4-pole, TRRS)
Power button


Maximum VGA length: 362 mm
Maximum CPU cooler height: 170 mm
Maximum PSU length: 200 mm
