CPU
- Support for an Intel Core 2 Extreme/Intel Core 2 Quad/Intel Core 2 Duo/Intel Pentium/Intel Celeron processor in the LGA775 package
- L2 cache varies with CPU
FRONT SIDE BUS
- 1333/1066/800 MHz FSB
CHIPSET
- North Bridge: Intel G41 Chipset
- South Bridge: Intel ICH7
MEMORY
- DDR3:
* 2× 1.5V DDR3 DIMM sockets supporting up to 4GB of system memory (due to Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
* Dual channel memory architecture
* Support for DDR3 1333(O.C.)/1066/800 MHz memory modules
- DDR2:
* 2× 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory (due to Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
* Dual channel memory architecture
* Support for DDR2 1066(O.C.)/800/667 MHz memory modules
- Note: Mixed mode, populating DDR2 and DDR3 memory modules simulta-neously is not supported
ONBOARD GRAPHICS
- North Bridge: 1× D-Sub port
AUDIO
- VIA VT1708S codec
- High Definition Audio
- 2/4/5.1-channel
- Support for S/PDIF Out
- Support for CD In
LAN
- 1× Atheros AR8151 chip (10/100/1000 Mbit)
EXPANSION SLOTS
1× PCI Express x16 slot, running at x16
1× PCI Express x1 slot
2× PCI slots
STORAGE INTERFACE
- South Bridge:
* 1× IDE connector supporting ATA-100/66/33 and up to 2 IDE devices
* 4× SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
- iTE IT8718F chip:
* 1× floppy disk drive connector supporting up to 1 floppy disk drive
USB
- South Bridge: Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
INTERNAL I/O CONNECTORS
1× 24-pin ATX main power connector
1× 4-pin ATX 12V power connector
1× floppy disk drive connector
1× IDE connector
4× SATA 3Gb/s connectors
1× CPU fan header
1× system fan header
1× front panel header
1× front panel audio header
1× CD In connector
1× S/PDIF Out header
2× USB 2.0/1.1 headers
1× serial port header
1× clearing CMOS jumper
BACK PANEL CONNECTORS
1× PS/2 keyboard port
1× PS/2 mouse port
1× parallel port
1× serial port
1× D-Sub port
4× USB 2.0/1.1 ports
1× RJ-45 port
3× audio jacks (Line In/Line Out/Microphone)
I/O CONTROLLER
- iTE IT8718F
H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System fan fail warning
- CPU fan speed control (whether the CPU fan speed control function is supported will depend on the CPU cooler you install)
BIOS
- 2× 8 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
UNIQUE FEATURES
- Support for @BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune (Available functions in EasyTune may differ by motherboard model)
- Support for Easy Energy Saver (Due to the hardware limitation, you must install the IntelCore 2 Extreme/ Core 2 Quad/Core 2 Duo/ Pentium Dual-Core/ Celeron Dual-Core/ Celeron 400 Series CPU to enable support for Easy Energy Saver)
- Support for SMART Recovery
- Support for Auto Green
- Support for ON/OFF Charge
- Support for Q-Share
OPERATING SYSTEM
- Support for Microsoft Windows 7/Vista/XP
FORM FACTOR
- Micro ATX Form Factor (24.4×21.0 cm)
