CPU
- Support for Intel Core i7/Intel Core i5/Intel Core i3/Intel Pentium/Intel Celeron processors in the LGA1155
- L3 cache varies with CPU
CHIPSET
- Intel H67 Express Chipset
MEMORY
- 4× 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory (due to Windows 32-bit operating system limitation, when more than 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
- Dual channel memory architecture
- Support for DDR3 1333/1066/800 MHz memory modules
- Support for non-ECC memory modules
- Support for Extreme Memory Profile (XMP) memory modules
AUDIO
- Realtek ALC889 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for S/PDIF Out
LAN
- 1× Realtek RTL8111E chip (10/100/1000 Mbit)
EXPANSION SLOTS
- 1× PCI Express x16 slot, running at x16 (PCIEX16) (for optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot)
- 1× PCI Express x16 slot, running at x4 (PCIEX4) (when the PCIEX1_2 or PCIEX1_3 slot is populated with an expansion card, the PCIEX4 slot will operate at up to x1 mode)
- 3× PCI Express x1 slots (all PCI Express slots conform to PCI Express 2.0 standard)
- 2× PCI slots
MULTI-GRAPHICS TECHNOLOGY
- Support for ATI CrossFireX (the PCIEX16 slot operates at up to x4 mode when ATI CrossFireX is enabled)
STORAGE INTERFACE
- 2× SATA 6Gb/s connectors (SATA3_0, SATA3_1) supporting up to 2 SATA 6Gb/s devices
- 4× SATA 3Gb/s connectors (SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 4 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 (when a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the system performance of the RAID set may vary depending on the devices being connected)
USB
- Chipset: Up to 14 USB 2.0/1.1 ports (10 on the back panel, 4 via the USB brackets connected to the internal USB headers)
INTERNAL I/O CONNECTORS
1× 24-pin ATX main power connector
1× 8-pin ATX 12V power connector
2× SATA 6Gb/s connectors
4× SATA 3Gb/s connectors
1× CPU fan header
2× system fan headers
1× power fan header
1× front panel header
1× front panel audio header
1× S/PDIF Out header
2× USB 2.0/1.1 headers
1× serial port header
1× clearing CMOS jumper
BACK PANEL CONNECTORS
1× PS/2 keyboard/mouse port
1× coaxial S/PDIF Out connector
1× optical S/PDIF Out connector
10× USB 2.0/1.1 ports
1× RJ-45 port
6× audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line Out/Microphone)
I/O CONTROLLER
- iTE IT8728 chip
H/W MONITORING
- System voltage detection
- CPU/System temperature detection
- CPU/System/Power fan speed detection
- CPU overheating warning
- CPU/System/Power fan fail warning
- CPU/System fan speed control (whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install)
BIOS
- 2 x 32 Mbit flash
- Use of licensed AWARD BIOS
- Support for DualBIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
UNIQUE FEATURES
- Support for @BIOS
- Support for Q-Flash
- Support for Xpress BIOS Rescue
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune (available functions in EasyTune may differ by motherboard model)
- Support for Dynamic Energy Saver 2
- Support for Smart 6
- Support for Auto Green
- Support for eXtreme Hard Drive (X.H.D)
- Support for ON/OFF Charge
- Support for Cloud OC
- Support for Q-Share
OPERATING SYSTEM
- Support for Microsoft Windows XP/Vista/7
FORM FACTOR
- ATX Form Factor (30.5×21.5 cm)
